Planetary counter-flow concrete mixer BPP-3V-375 is a forced concrete mixer, the working bodies of which make a complex movement in a dish-shaped container.

The principle of mixing in the planetary concrete mixer BPP-3V-375

Mixing shafts and blades rotate around the concrete mixer vertical shaft and about its axis at the same time.

The blades move along complex circular trajectories, which causes the components of the mixture to collide in oncoming flows. This makes it possible to obtain good homogeneity when mixing small volumes of finely dispersed components into the main volume of the mixture (for example, when adding dyes).

Water in planetary mixers, in the production of ultra-rigid concrete mixtures, is usually supplied under pressure through a sprayer, which ensures uniform wetting of the super-rigid mixture throughout the batch.

Однако при производстве сверхжестких бетонных смесей, в состав которых входят компоненты, имеющие различную насыпную плотность, планетарные смесители проявляют себя хуже, чем двухвальные бетоносмесители. Это объясняется тем, что лопасти движутся в горизонтальной плоскости, что приводит к расслоению такой смеси. Легкие и крупные частицы «всплывают» под воздействием гравитации, что хорошо просматривается при производстве сверхжестких смесей на керамзите, древесных опилках, смесей для фибробетонов и полистеролбетонов. Для производства таких смесей рекомендуется применять двухвальные бетоносмесители.

Mixing takes place with double circular motions of the blades, the blades cover the entire bottom of the mixer in 12 seconds.

CAMOZZI pneumatic gate - two-side

Planetary concrete mixer BPP-3V-375 intended for the preparation of semi-dry mixtures used for vibrocompression and mortars.

Recommended for preparing super-hard concrete mixes!

Planetary compulsory concrete mixer BPP-3V-375 loading volume 375 liters, ready concrete output 250 liters.

Concrete mixer is equipped with a one prison with management hydraulic cylinder. Для управления гидрозатвором используется маслостанция, она входит в базовую комплектацию..

The armored elements of the concrete mixer body are made of become hardness HRC58… 60.

Concrete mixer blades are made of wear resistant cast iron hardness HRC60… 62.

В корпусе для контроля за производством бетонной смеси имеется два смотровых люка, которые оснащены средствами безопасности в виде концевых выключателей.

Power mixer drive 11 Kw, planetary reducer.

To improve the quality and speed of mixing, the concrete mixer is equipped with a water supply system with water spray through special nozzles.

. An oil station is used to control the hydraulic seal, it is included in the basic package.

• mixtures for fiber-reinforced concrete and polysterol concrete. For the production of such mixtures, it is recommended to use twin-shaft concrete mixers.
• mixtures for fiber-reinforced concrete and polysterol concrete. For the production of such mixtures, it is recommended to use twin-shaft concrete mixers.
• mixtures for fiber-reinforced concrete and polysterol concrete. For the production of such mixtures, it is recommended to use twin-shaft concrete mixers.
• mixtures for fiber-reinforced concrete and polysterol concrete. For the production of such mixtures, it is recommended to use twin-shaft concrete mixers.

. An oil station is used to control the hydraulic seal, it is included in the basic package.

• gravitational separation of mixture components having different bulk mass
• significant mixer unloading time

CAMOZZI pneumatic gate - two-side

Technical Features

• Loading volume, l 375
• Ready-mix concrete volume, l 250
• Mixing mechanism drive power, kW 11
• Shutter drive power, kW 2,2
• Total power, kW 13,2
• Number of mixing blades 1x2
• Number of scraper blades 2
• Power Supply, 380
• frequency Hz 50
• Unloading gravitational separation of mixture components having different bulk mass
• Water spray Nozzles
• Planetary frame speed, rpm 14,6
• Planetary shaft speed, rpm 46
• Width, mm 1557
• Length, mm 1648
• Height, mm 1772
• Weight, kg 1600
