Automatic line MAXIMAL
on hydraulic lift
62 509 216 ₸
Price depends on the exchange rate
Worldwide shipping
2-year warranty
Plant passport, PDF
Enquire conditions
and delivery time
We'll call you back within 15 minutes
Specify your requirements
Send prices and terms of delivery
| Frame vibropress 4 and guide crosspiece |
| Vibrating table synchronized unbalance in an oil bath. Power 11 kW |
| Frequency converter |
| Hopper 1.2 cubic meters. meters with a hydraulic damper |
| The loading module mixture passive agitator, hydraulic actuator |
| Synchronizer guide matrix |
| Puansonoderzhatel with a vibrator |
| synchronizer punch |
| Protective grid for safety |
| Hydroelectric power station 11.5 kW |
| feed module trays with conveyor and pallet magazine for 10 pieces |
| Roller conveyor to receive the finished product |
| Special brushes for removing burrs on the products |
| Technology pan - 1 piece |
| Hydraulic lift (for collecting pallets with molded products) |
| Hydropower |
| Chain conveyor |
| The system for cleaning of finished goods from the pallet and shipping pallet assembly |
| The system for the collection, cleaning, revolution and feeding a pallet process vibropress |
| Roller conveyor for cleaning the packed shipping pallets with finished products |
| Hydraulic station with a power of 9.5 kW, for the unloading line of finished products |
| Пульт автоматический по принципу "одна кнопка" для вибропресса МАКСИМАЛ |
| power cabinet |
| Passport to vibropress |
| Toolkit for the selection of concrete mixtures |
| The punch-matrix according to the customer's sketches |
| Загрузочный модуль "цветного слоя" |
| technological pallets |
| Press splitting the PC-20 wall stones |
| Press for splitting stones 60 tons, 800 mm. |
| Press for splitting stones 80 tons, 800 mm. |
| BP-1G-100 Concrete Mixer |
| BP-2G-185 Twin-shaft concrete mixer |
| BP-2G-375 Twin-Shaft Concrete Mixer |
| BP-2G-750 Twin-shaft concrete mixer |
| LK 5-0,5 Belt Conveyor |
| Concrete plant STANDARD-15 |
| MOBIL-20 Concrete Plant |
| Concrete plant COMPACT 20 |
Line-based vibropress MAXIMUM - we have collected the maximum number of pripressovogo equipment to eliminate unnecessary manual operations and human factors in the production of vibropressed products.
Линия работает в полностью автоматическом режиме, оператор контролирует всю работу на сенсорном дисплее 10″. Пооперационные этапы работы линии:
- Molding Technology vibropressovannykh products on a pallet in an automatic mode,
- The movement of pallets with molded products in the hydraulic lift (2 pcs. On one floor)
- Stacking products in stacks of 2 pieces at the same level
- Cleaning technological pallets with products in the aging zone (steaming chamber) using a loader
- Pallets with dried products are fed into the hydraulic reducer for removal from technological pallets
- Removing finished products gidroskhvatom and laying on the shipping pallet for cleaning truck to the warehouse
- Purification and supply, empty pallets in a pallet tilter revolution (for uniform wear and load), and further in the pallet storage device for re-cycle.
- DOES NOT REQUIRE RACKING
- TAKES MINIMUM PLACES IN A VESTING CAMERA
- The size of the molding 1000h600 zone - the highest performance in its class
- 11 kW vibrating table with frequency converter
- Ultra-compact line with the dimensions of 8800 x 9200
- Fully automatic block-making on the principle of "one button"
- Fully automatic operation of collecting trays with a molded article stacker
- Fully automatic operation for collecting the finished product from the pallet and packing it
- Remote control operation line operator with a touch screen 10 "
- The wide range of products
- Form 2 at the same time curb traffic in accordance with GOST
- Shot peening prior to application to the extent Sa 2 1/2 GOST P ISO 8501-1-2014
- Anti-corrosion protection with a two-component primer-enamel in a painting and drying chamber
- 2-year warranty
Technical Features
- The size of the molding zone, mm x mm 1000 x 600
- The height of the molding zone, mm 50...300
- molding cycle s 30-60
- Power vibration table, kW 11
- Total installed power, kW 36
- The frequency of the vibrating table fluctuations, Hz 45...85
- Hydraulic pressure, MPa 6...12
- The number of moldings per hour piece. 60...120
- Supply voltage, V/Hz 380/50
- Hopper capacity, cu. m 1,2
- Download matrix Boot box with passive turner, hydraulic actuator
- filing trays Store pallets, hydraulic actuator
- pallet storage system stockpilers
- The system for the collection of finished products from pallets hydraulic cuber
- mode Auto
- Length, mm 8,000
- Width, mm 8500
- Height, mm 4,500
- Weight, kg 13500
