FLAGMAN-90 concrete plant is operated in automatic mode in automatic mode in accordance with the single button principle. The operator needs to choose grade of concrete (M50 ... M500) and its amount for loading, and to press the button to start the cycle.
Design of concrete plant - all-weather.
PA 2.0 control panel is located inside a winterized cab. It's equipped with three windows and a door - for the operator's comfortable visual inspection of all plant's operations.
All equipment of the concrete plant and winterized carcase are installed on a reinforced mounting frame which is placed on a level ground. No foundation or skip pit needed.
Twin-shaft concrete mixer BP-2G-2250s is mounted on an elevated structure. Discharge height - 4 m. The concrete mixer is fitted with a skip for mixture hoisting and feeding.
For storage and dispensing inert materials: DKM-54 batching complex. There are three hoppers of 18 cu m each. Total capacity is 54 cu m. A dispensing conveyor belt where component batching is performed is installed under the hoppers. Components are fed from the hoppers by opening of Camozzi pneumatically operated gates (Italy). Upon achievement of the required batch of inert materials, the conveyor is turned on, and inert materials are fed into the skip that hoists the components to the concrete mixer. The hoppers are equipped with inert materials heating registers during a cold period and heat-insulated covers for protection against atmospheric fallout. The concrete plant is equipped with service areas heating registers. The registers are linked up by the steam pipe system for connection to any type of heating centre.
The cement is stored in a special warehouse - cement silo (not included in the basic package). Silos for cement must be selected the rate of two daily stock performance. For feeding cement from a cement silo dispenser must acquire the correct length screw.
Силосы цемента, обвязка для силоса и шнеки всегда в наличии на складе в Златоусте! Производитель “SCUTTI” (Италия)
Cement, water and chemical additives are batched in BD-90 block if dispensers. Cement is batched in cement dispenser with maximum dosage 900 kg.
Water is batched in water dispenser with maximum dosage 450 litres. Chemical additives are batched in 60 litres dispenser. All components of the mixture are mixed; upon achievement of required homogeneity of the mixture, Camozzi pneumatically operated gate is opened, and the mixture is discharged into a concrete mixer lorry or a receiving hopper.
Then the cycle is repeated.
One cycle lasts for 55-60 seconds during which 1.5 cu m of ready-to-use concrete is produced.
Возможна поставка бетонного завода в защитном покрытии цинк. Покрытие наносится методом холодного цинкования.
